Gardner Denver AUTO SENTRY EAU99P - Coupling Assembly Procedure; Coupling Element Replacement

To Next Page

To Previous Page

13-10-615 Page 62

SECTION 7

COUPLING

Figure 7-1 – INSTALLATION OF COUPLING CUSHIONS

Rotating machinery can cause personal injury or death. Turn the unit

completely off, open the main disconnect, lockout and tagout before servicing

the coupling.

COUPLING - The motor and compressor are direct connected by a resilient type flexible coupling with a

single element cushion. The coupling does not require lubrication.

If maintenance on mating parts is required, reassemble coupling as follows:
