13-10-615 Page 33

COMPRESSOR CAPACITY CONTROL

The capacity of the compressor is controlled by the action of the Turn Valve and the Compressor Inlet

Valve.

The turn valve controls compressor delivery to match demands of 40% to 100% of the compressor’s

maximum capacity. The inlet valve throttles to control compressor delivery to match demands of 0% to

40% of the compressors maximum capacity.

Example with normal setting of 100 PSIG:

Compressor Delivery

Inlet Valve Position

Turn Valve Position

Discharge Manifold

Pressure

(psi)

Full Capacity Open Closed 100

70% Capacity Open 50% Open 100

40% Capacity Open Full Open 100

30% Capacity Closing Full Open 103

20% Capacity Closing Full Open 103

0% Capacity Closed Full Open 103
