7) As the CDI approaches center, the aircraft turns onto the active leg as seen in Figure 5-123.
Figure 5-123 Turn on to Active Leg
8) At SLN, Victor Airway 244 (V244) is intercepted. Turn prompts are displayed in the PFD Navigation Status Box
as seen in Figure 5-124.
Figure 5-124 Turn to Intercept V244
