10
If you are on a computer running Windows software, select
Next, select the drive associated with the memory card, and
select Next > Finish.
A Garmin folder containing the software update is created on
the memory card. The software update can take several
minutes to load onto the memory card.
11
If you are on a Mac computer, copy the Garmin folder to the
root directory of the memory card.
The software update can take several minutes to load onto
the memory card.
After loading the update onto the memory card, install the
software on the chartplotter (Updating the Device Software,
page 64).
Updating the Device Software
Before you can update the software, you must obtain a
software-update memory card or load the latest software onto a
memory card (Loading the New Software on a Memory Card,
page 63).
1
Turn on the chartplotter.
2
After the home screen appears, insert the memory card into
the card slot.
NOTE: In order for the software update instructions to
appear, the device must be fully booted before the card is
inserted.
3
Follow the on-screen instructions.
4
Wait several minutes while the software update process
completes.
5
When prompted, leave the memory card in place and restart
the chartplotter manually.
6
Remove the memory card.
NOTE: If the memory card is removed before the device
restarts fully, the software update is not complete.
Pairing the GRID Device with the
Chartplotter from the Chartplotter
NOTE: These steps are applicable to both the GRID device and
the GRID 20 device.
Before you can pair the GRID 20 device with the chartplotter to
make the data connection, you must supply power using
batteries, the included power cable, or a NMEA 2000 network
connection.
Before you can pair the GRID device with the chartplotter, you
must connect it to the Garmin Marine Network.
1
Select Settings > System > Station Information > GRID™
Pairing > Add.
2
Select an action:
• On the GRID remote input device, press SELECT.
• On the GRID 20 remote input device, press and until
the remote control beeps three times.
Pairing the GRID Device with the Chartplotter from
the GRID Device
NOTE: This is not applicable to the GRID 20 device.
1
On the GRID remote input device, press + and HOME at the
same time.
A selection page opens on all of the chartplotters on the
Garmin Marine Network.
2
Rotate the wheel on the GRID remote input device to
highlight Select on the chartplotter you want to control with
the GRID remote input device.
3
Press SELECT.
Rotating the GRID Remote Input Device
For certain installation situations, you can rotate the orientation
of the GRID device.
NOTE: This is not applicable to the GRID 20 device.
1
Select Settings > Communications > Marine Network.
2
Select the GRID device.
Cleaning the Screen
NOTICE
Cleaners containing ammonia will harm the anti-reflective
coating.
The device is coated with a special anti-reflective coating which
is very sensitive to waxes and abrasive cleaners.
1
Apply an eyeglass lens cleaner specified as safe for anti-
reflective coatings to the cloth.
2
Gently wipe the screen with a soft, clean, lint-free cloth.
Viewing Images on a Memory card
You can view images that are saved on a memory card. You
can view .jpg, .png, and .bmp files.
1
Insert a memory card with image files into the card slot.
2
Select Info > Image Viewer.
3
Select the folder containing the images.
4
Wait a few seconds for the thumbnail images to load.
5
Select an image.
6
Use the arrows to scroll through the images.
7
If necessary, select Menu > Start Slideshow.
Screenshots
You can capture a screenshot of any screen shown on your
chartplotter as a .png file. You can transfer the screenshot to
your computer. You can also view the screenshot in the image
viewer (Viewing Images on a Memory card, page 64).
Capturing Screenshots
1
Insert a memory card into the card slot.
2
Select Settings > Preferences > Screenshot Capture >
On.
3
Go to a screen you want to capture.
4
Hold Home for at least six seconds.
Copying Screenshots to a Computer
1
Remove the memory card from the chartplotter, and insert it
into a card reader that is attached to a computer.
2
From Windows Explorer, open the Garmin\scrn folder on the
memory card.
3
Copy a .bmp file from the card and paste it to any location on
the computer.
Troubleshooting
My device will not acquire GPS signals
If the device is not acquiring satellite signals, there could be a
few causes. If the device has moved a large distance since the
last time it has acquired satellites or has been turned off for
longer than a few weeks or months, the device may not be able
to acquire the satellites correctly.
• Ensure the device is using the latest software. If not, update
the device software (Software Update, page 63).
• Make sure the device has a clear view of the sky so the
antenna can receive the GPS signal. If it is mounted inside of
a cabin, it should be close to a window so it can receive the
GPS signal.
64 Appendix
