Chapter 6 143
NOTE: Part numbers may be different depending on your model. Please refer to the FRU List for a full listing
of part numbers.
8 Main Board MB.SA506.001*
9 Thermal Module UMA Assy 60.SA107.006
10 Base Sub Assy 60.WF807.002
11 RAM KN.2GB03.011*
12 RAM Door Assy 42.WF807.001
13 Touch Pad Board Assy 55.WF807.004
14 Bluetooth Module BH.21100.004
15 Cardreader Cable FCC 50.SA107.003
16 Battery BT.00607.106*
17 LAN Board Assy 55.WF807.003
18 SD Dummy Card 42.WF807.003
19 HDD KH.16001.042*
20 HDD Mylar TBD
21 Cable FPC HDD 50.SA107.006
22 WLAN Card NI.23600.046*
23 Rubber Base 47.WF807.002
24 HDD Door Assy 42.WF807.002
Item Description Part Number
To Next Page
