8 Chapter 1
Base View
Rear View
Icon Item Description
Battery bay Houses the computer’s battery pack.
Note: The battery shown is for reference only. Your PC may have a
different battery depending on the model purchased.
Battery lock Locks the battery in position
Hard disk bay Houses the computer’s hard disk (secured with screws)
Memory
compartment
Houses the computer’s main memory.
Ventilation slots
and cooling fan
Enable the computer to stay cool, even after prolonged use.
Note: Do not cover or obstruct the opening the fan.
Battery release
latch
Releases the battery for removal.
Icon Item Description
Battery bay Houses the computer’s battery pack.
Note: The battery shown is for reference only. Your PC may have a
different battery depending on the model purchased.
Ventilatio
slots and
cooling f
