80 Chapter 3
Removing the LCD Brackets
1. See “Removing the LCD Panel” on page 78.
2. Remove the four LCD bracket screws.
Screw List
Step Screw Quantity Screw Type
LCD Brackets
Disassembly
M2*2.5 4
