Gateway EC14 - LCD Module Disassembly Process; LCD Module Disassembly Flowchart

Chapter 3 75
LCD Module Disassembly Process
IMPORTANT: Cable paths and positioning may not represent the actual model. During the removal and
replacement of components, ensure all available cable channels and clips are used and that the cables are
replaced in the same position.
NOTE: The product previews seen in the disassembly procedures may not represent the final product color or
configuration.
LCD Module Disassembly Flowchart
Screw List
Step Screw Quantity Part No.
Remove LCD
Brackets
2*2.5 4 86.SA107.002
Remove LCD
Panel
2*3 4 86.SA107.001
Remove
LCD Brackets
Remove
Camera Module
Remove
LCD FPC Cable
Remove LCD
Panel from Main
Unit before
proceeding
Remove
LCD Panel
Remove
Antennas
Detach
Microphone
Remove
LCD Bracket
Bezel
