GATEXPERT DKC500ACL - A Intelligent Control Board; Programming and Wiring

Instructions for DKC500ACL/DKC800ACL
www.gatexpertstore.com
15
J5 Terminal
Hall Sensor
J3 Terminal
Dip Switches
Learn Button
Potentiometers
A Intelligent Control Board
Programming and Wiring
Any works to the 110V AC must only be performed by a licensed electrician.
Ensure power is off before any modifications are made.
Fuse
(10A 250V fuse)
J4 Terminal
J6 Terminal
J2 Terminal
Figure 16
