GATEXPERT DKC500ACL - B Standard Control Board; Programming and Wiring

Instructions for DKC500ACL/DKC800ACL
www.gatexpertstore.com
22
B Standard Control Board
Programming and Wiring
Any works to the 110V AC must only be performed by a licensed electrician.
Ensure power is off before any modifications are made.
Fuse
(10A 250V fuse)
Dip Switches
LEARN Button
Motor Direction
Switch
Figure 22
X2 Terminal
X3 Terminal
X1 Terminal
X5 Terminal
X4 Terminal
