Instructions for DKC500ACL/DKC800ACL
www.gatexpertstore.com
4
No.
Name
Quantity
4-9
Anchor Bolts M8
4
4-10
Magnetic Limit Switch Stop
2
Magnets
2
Hexagon Head Bolt M6X65
4
Nut M8
4
Flat Washer φ8
2
Spring Washers φ8
2
4-11
Inner Hexagon Head Bolt M6X20
4
4-12
Hexagon Head Bolt M8X40
4
4-13
Nut M6
16
Nut M8
16
4-14
Flat Washer φ6
16
Flat Washer φ8
16
4-15
Spring Washers φ6
16
Spring Washers φ8
12
Note: Extra flat washers and spring washers are spare parts.
Parts List (optional)
No.
Name
Quantity
1
Infrared Photocell
1
2
Wireless Keypad
1
3
Alarm Lamp
1
