Changing Die Sets 2-5
2
6 Grasp the base of the Die and lift straight up, as shown in Figure 2-3.
Figure 2-3: Removing and replacing the Die Assembly
7 To replace the Die, repeat Steps 1 through 6 in reverse order.
Note: The Die assembly is keyed and will reinstall only one way.
