Clearing Jams 3-3
3
Clearing Jams
A good rule for clearing jams is to follow the paper path through the Punch
and Bypass Stacker, from left to right. The jam clearing procedures are as
follows:
1 Press the Stop/Reset button on the Punch Control Panel.
2 Open both Top Covers on the Punch, as shown in Figure 3-1.
3 Open (lift) the Input Ball Tracks, as shown in Figure 3-1, and clear any
paper that may be jammed in that area. Also, check the printer Finisher
and output tray for any paper jams.
Figure 3-1: The Top Covers and Input Ball Tracks
Input Ball
Tracks
Assembly
To p C o v e r s
To Next Page
