Set Lens Page
The Set Lens Page allows you to modify the lens setting after you have changed to a different
focal lens. Remember to save your settings after you have made the proper changes. Now by
pressing the Auto Focus button, the LaserPro X252RX & X380RX will auto focus properly using
the new lens setting. The LaserPro X252RX & X380RX’s default setting is <2.0”>
 Lens: 2.0” / 4.0”
Set Lens Page
Relevant Buttons
Function
F1 (Back)
Back to previous page
F4 (Save)
Save your current settings



/


 Directional
Cycle through selections
Start / Stop Back to Main Work Page
Auto Focus Initiate the auto focus function
▲ / ▼
Manual Focus
Buttons
Manually adjust the height of the work table (Z-
axis)
Main Work Page
Press
F
4
☼
Navigating to this page:
Functions Page
Select <
Machine Setting
>
from the menu
Machine Setting Page
Select <
Set Lens
>
from the menu
Set Lens Page
