- 38 - 232001240G(08)
Tune Auto Focus Page
The Tune Auto Focus Page allows you to manually set the default auto focus distance / vertical
height of the worktable (Z-axis) for when the Auto Focus button is pushed.
Tune Auto Focus Page
Relevant Buttons
Function
F1 (Back) Back to previous page
F4 (Save)
Save your current settings



/



Directional
Manually adjust the height of the work table (Z-
axis)
Start / Stop Back to Main Work Page
Auto Focus Initiate the auto focus function
▲ / ▼
Manual Focus
Buttons
Manually adjust the height of the work table (Z-
axis)
Main Work Page
Press
F4
☼
Navigating to this page:
Functions Page
Select <
Machine
Setting> from the menu
Machine Setting Page
Select <
Tune Auto Focus
>
from the menu
Tune Auto Focus Page
