16 1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual
Connecting the ZE2016 and ZE2064 zone LED modules
The ZE2016 and ZE2064 zonle LED modules are used to increase the number of
visible zones for 1200C and 2000C control panels.
The maximum number of zone modules that can be installed will depend on the
control panel model – see “Appendix C: Maximum zones and loops” on page 38 for
more information.
The ZE2016 and ZE2064 modules are located on the inside of the control panel door
and are connected to the HDIS2000N or HDIS2000-F LED display module.
Caution: The ZE2016 and ZE2064 zone LED modules must ntot be installed together
in the same control panel.
