1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual 1
Installation and commissioning
WARNING: This product must be installed and maintained by qualified personnel
adhering to the CEN/TS 54-14 standard (or the corresponding national standard) and
any other applicable regulations.
Cabinet layout for 1200C control panels
Figure 1: Typical cabinet layout for 1200C control panels
1. FEP2000N mains controller module
2. PS1200N power supply interface module
3. LC1502 loop module
4. SD2000 common I/O module
5. PS2000N power supply unit
6. Earth stud
7. Fuse terminal block
8. 12V batteries
For detailed module information for all control panels see “Appendix A: Modules” on
page 35
