GE Security 1200C Installation Manual

1200C-2000C Fire Alarm Control Panel, Repeater, and Black Box Installation Manual 33
Power supply
FR1216C FR2064C All other panels
Input 230 VAC (+10%, -
15%), 50 Hz (±10%)
21 to 28 VDC 230 VAC (+10%, -
15%), 47 to 63 Hz
50 VA 24V standby battery 200 VA
21 to 28 VDC 21 to 28 VDC
24V standby battery 24V standby battery
Output Aux. Power:
19 to 28.8 VDC
100 mA (max.)
Aux. Power
19 to 28.8 VDC
1 A (max.)
Modem:
5 VDC (±0.1V)
75 mA (max.)
Battery charge:
27.3 VDC at 20°C,
36 mV/°C
Battery charge:
27.6 VDC (±0.2V) at
25°C, 300 mA (max.)
Supervised Mains fail
Battery disconnect
Battery flat
Flat battery cut-out
Earth fault
Auxiliary supply fault
Mains fail
Charger fail
Input voltage
Earth fault
Charger fault
Battery loss
Battery fault
Mains fuse T 0.8A 250V T 1A 250V T 2A 250V
Maximum current (primary input) 250 mA 0.3 A (no options
installed)
1A
Maximum output ripple voltage ±300 mV ±300 mV
Fault relay (subject to jumper
configuration)
Maximum switching
current:
2A at 24 VDC
Maximum power
rating:
50 W
Maximum switching
current:
2A at 24 VDC
Maximum power
rating:
50 W
Current requirements
Status System Aux. Printer Modem Loops* Sounders Total
Standby 200 mA 1 A 100 mA 200 mA 340μA per
device
0 < I max a.
1 A
Alarm 200 mA +
10 mA per
zone card
1 A 100 mA 200 mA 340μA per
device plus
80 mA per loop
200 mA < I max b.
4 A
* Do not exceed 250 mA per loop.

GE Security 1200C Specifications

General

Brand	GE Security
Model	1200C
Category	Control Panel
Language	English
