GE Power Management 469 Motor Management Relay 4-73
4 SETPOINT PROGRAMMING 4.12 S11 MONITORING
4
Figure 4–20: TRIP COIL SUPERVISION
TRIP COIL
SUPERVISION
R1 TRIP
CONTACT
VALUE OF RESISTOR 'R'
52a
TRIP
COIL
TRIP
COIL
TRIP
COIL
SUPPLY
OHMS
WATTS
48 VDC
125 VDC
250 VDC
10 K
25 K
50 K
2
5
5
F11
E2
F1
E11
TRIP COIL
SUPERVISION
R1 TRIP
CONTACT
F11
E2
F1
E11
TRIP COIL
SUPERVISION
R1 TRIP
CONTACT
F11
E2
F1
E11
52a
52a
52a
TRIP COIL CLOSED SUPERVISION
"52 Closed"
TRIP COIL OPEN/CLOSED SUPERVISION
"52 Open/Closed"
TRIP COIL
OPEN/CLOSED
SUPERVISION
"52 Open/Closed"
WITH MULTIPLE
BREAKER AUX
CONTACTS
