GE 469

5-18 469 Motor Management Relay GE Power Management
5.4 A3 LEARNED DATA 5 ACTUAL VALUES
5
5.4.3 RTD MAXIMUMS
The 469 will learn the maximum temperature for each RTD. This information can be cleared using the
S1 469
SETUP \ CLEAR DATA \ CLEAR RTD MAXIMUMS
setpoint.
If no RTDs are programmed in
S8 RTD TEMPERATURE
, the following flash message will appear when an attempt
is made to enter this group of messages.
y
RTD MAXIMUMS
y
[ENTER] for more
RTD #1
MAX. TEMP.: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Seen only if at least 1 RTD programmed as Stator
RTD #2
MAX. TEMP.: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
RTD #3
MAX. TEMP.: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
RTD #4
MAX. TEMP.: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
RTD #5
MAX. TEMP.: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
RTD #6
MAX. TEMP.: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
RTD #7
MAX. TEMP.: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
RTD #8
MAX. TEMP.: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
RTD #9
MAX. TEMP.: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
RTD #10
MAX. TEMP.: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
RTD #11
MAX. TEMP.: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
RTD #12
MAX. TEMP.: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted). Not seen if
RTD set to None; reflects RTD Name as programmed
THIS FEATURE NOT
PROGRAMMED
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
