5-10 469 Motor Management Relay GE Power Management
5.3 A2 METERING DATA 5 ACTUAL VALUES
5
5.3.2 TEMPERATURE
The current level of the 12 RTDs is displayed here. If the RTD is not connected, the value will be
"No RTD"
.
If no RTDs are programmed in
S8 RTD TEMPERATURE
, the following flash message will appear when an attempt
is made to enter this group of messages.
y
TEMPERATURE
y
[ENTER] for more
HOTTEST STATOR RTD
RTD#1: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Seen only if at least 1 RTD programmed as Stator
RTD #1
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Not seen if RTD set as None; reflects RTD Name as programmed
RTD #2
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Not seen if RTD set as None; reflects RTD Name as programmed
RTD #3
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Not seen if RTD set as None; reflects RTD Name as programmed
RTD #4
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Not seen if RTD set as None; reflects RTD Name as programmed
RTD #5
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Not seen if RTD set as None; reflects RTD Name as programmed
RTD #6
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Not seen if RTD set as None; reflects RTD Name as programmed
RTD #7
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Not seen if RTD set as None; reflects RTD Name as programmed
RTD #8
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Not seen if RTD set as None; reflects RTD Name as programmed
RTD #9
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Not seen if RTD set as None; reflects RTD Name as programmed
RTD #10
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Not seen if RTD set as None; reflects RTD Name as programmed
RTD #11
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Not seen if RTD set as None; reflects RTD Name as programmed
RTD #12
TEMPERATURE: 40°C
Range: –50 to 250°C, No RTD (open), ---- (shorted)
Not seen if RTD set as None; reflects RTD Name as programmed
THIS FEATURE NOT
PROGRAMMED
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
