5.2 A1 STATUS 5 ACTUAL VALUES
5
5.2 A1 STATUS 5.2.1 MOTOR STATUS
These messages describe the motor status at any given point in time. If the motor has been tripped and the
469 has not yet been reset, the
MOTOR STATUS
value will be
"Tripped"
. The
MOTOR THERMAL CAPACITY USED
reflects an integrated value of both the Stator and Rotor Thermal Capacity Used. The values for
ESTIMATED
TRIP TIME ON OVERLOAD
appear whenever the 469 picks up on the overload curve.
y
MOTOR STATUS
y
[ENTER] for more
MOTOR STATUS:
Stopped
Range: Tripped, Stopped, Starting, Running, Overload
MOTOR THERMAL
CAPACITY USED: 0%
Range: 0 to 100%
ESTIMATED TRIP TIME
ON OVERLOAD: Never
Range: 0 to 10000 sec., Never
MOTOR SPEED:
Low Speed
Range: HIgh Speed, Low Speed
Message seen only if Two Speed Motor feature is enabled
ENTER
ESCAPE
ð
ð
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
