GE 469

GE Power Management 469 Motor Management Relay 4-89
4 SETPOINT PROGRAMMING 4.15 S14 TWO-SPEED MOTOR
4
SPEED2 TRIP AT
3.25 x FLA: 36.6 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
3.50 x FLA: 31.1 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
3.75 x FLA: 26.8 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
4.00 x FLA: 23.2 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
4.25 x FLA: 20.5 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
4.50 x FLA: 18.2 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
4.75 x FLA: 16.2 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
5.00 x FLA: 14.6 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
5.50 x FLA: 12.0 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
6.00 x FLA: 10.0 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
6.50 x FLA: 8.5 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
7.00 x FLA: 7.3 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
10.0 x FLA: 5.6 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
15.0 x FLA: 5.6 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 TRIP AT
20.0 x FLA: 5.6 s
Range: 0.5 to 99999.9; Step: 0.1
Cannot be altered if Standard Curve Style is selected.
SPEED2 MIN ALLOWABLE
LINE VOLTAGE: 80%
Range: 70 to 95%; Step: 1
Message seen only if Voltage Dependent Curve Style is selected
SPEED2 ISTALL @ MIN
Vline: 4.80 x FLA
Range: 2.00 to 15.00 x FLA; Step: 0.01
Message seen only if Voltage Dependent Curve Style is selected
SPEED2 SAFE STALL @
MIN Vline: 20.0 s
Range: 0.5 to 999.9 sec; Step: 0.1
Message seen only if Voltage Dependent Curve Style is selected
SPEED2 ACL INTERSECT
@ MIN Vline: 3.80 x FLA
Range: 2.00 to Istall@Min_Vline x FLA; Step: 0.01
Message seen only if Voltage Dependent Curve Style is selected
SPEED2 ISTALL @ 100%
Vline: 6.00 x FLA
Range: 2.00 to 15.00 x FLA; Step: 0.01
Message seen only if Voltage Dependent Curve Style is selected
