GE 469

6-18 469 Motor Management Relay GE Power Management
6.4 MEMORY MAP 6 COMMUNICATIONS
6
6.4.5 469 MEMORY MAP
Table 6–1: 469 MEMORY MAP (Sheet 1 of 43)
GROUP ADDR
(HEX)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
DEFAULT
Product ID (Addresses 0000 to 007F)
PRODUCT ID 0000 Product Device Code N/A N/A N/A N/A F1 30
0001 Product Hardware Revision 1 26 1 N/A F15 N/A
0002 Product Software Revision N/A N/A N/A N/A F16 N/A
0003 Product Modification Number 0 999 1 N/A F1 N/A
0004 Reserved
... ...
000F Reserved
0010 Boot Program Revision N/A N/A N/A N/A F16 N/A
0011 Boot Program Modification Number 0 999 1 N/A F1 N/A
0012 Reserved
... ...
007F Reserved
Commands (Addresses 0080 -00FF)
COMMANDS 0080 Command Function Code
0081 Reserved
0088 Communications Port Passcode 0 99999999 1 N/A F12 0
00F0 Time (Broadcast) N/A N/A N/A N/A F24 N/A
00F2 Date (Broadcast) N/A N/A N/A N/A F18 N/A
... ...
00FF Reserved
User Map (Addresses 0100 to 017F)
USER MAP
VALUES
0100 User Map Value # 1 --- --- --- --- --- ---
0101 User Map Value # 2 --- --- --- --- --- ---
... ...
017C User Map Value # 125 --- --- --- --- --- ---
017D Reserved
... ...
17FF Reserved
USER MAP
ADDRESSES
0180 User Map Address # 1 0 3FFF 1 hex F1 0
0181 User Map Address # 2 0 3FFF 1 hex F1 0
... ...
01FC User Map Address # 125 0 3FFF 1 hex F1 0
01FD Reserved
... ...
01FF Reserved
