GE 469

GE Power Management 469 Motor Management Relay 6-27
6 COMMUNICATIONS 6.4 MEMORY MAP
6
049F Reserved
TIMERS 04A0 Motor Running Hours 1 100000 1 hr F9 0
04A2 Time Between Starts Timer 0 500 1 min F1 0
04A3 Start Timer 1 0 60 1 min F1 0
04A4 Start Timer 2 0 60 1 min F1 0
04A5 Start Timer 3 0 60 1 min F1 0
04A6 Start Timer 4 0 60 1 min F1 0
04A7 Start Timer 5 0 60 1 min F1 0
04A8 Reserved
... ...
04BF Reserved
469 MODEL
INFO.
04C0 Order Code 0 65535 1 N/A FC136 N/A
04C1 Relay Serial Number 3050001 N/A 1 - F9 N/A
04C3 Reserved
... ...
04DF Reserved
CALIBRATION
INFO.
04E0 Original Calibration Date N/A N/A N/A N/A F18 N/A
04E2 Last Calibration Date N/A N/A N/A N/A F19 N/A
04E4 Reserved
... ...
04FF Reserved
PHASORS 0500 Va Angle 0 359 1 ° F1 N/A
0501 Vb Angle 0 359 1 ° F1 N/A
0502 Vc Angle 0 359 1 ° F1 N/A
0503 Ia Angle 0 359 1 ° F1 N/A
0504 Ib Angle 0 359 1 ° F1 N/A
0505 Ic Angle 0 359 1 ° F1 N/A
0506 Reserved
... ...
0FFF Reserved
Setpoints (Addresses 1000 to 1FFF)
PREFER-
ENCES
1000 Default Message Cycle Time 5 100 5 s F2 20
1001 Default Message Timeout 10 900 1 s F1 300
1002 Reserved
1003 Average Motor Load Calculation Period 1 90 1 min F1 15
1004 Temperature Display Units 0 1 1 - FC100 0
1005 Trace Memory Trigger Position 1 100 1 % F1 25
1006 Trace Memory Buffers 1 16 1 cycles F1 8
1007 Display Update Interval 1 60 1 s F2 4
1008 Cyclic Load Filter Interval 0 32 1 cycles F1 0
1009 Passcode (Write Only) 0 99999999 1 N/A F12 0
100B Encrypted Passcode (Read Only) N/A N/A N/A N/A F12 N/A
100C Reserved
Table 6–1: 469 MEMORY MAP (Sheet 10 of 43)
GROUP ADDR
(HEX)
DESCRIPTION MIN. MAX. STEP
VALUE
UNITS FORMAT
CODE
DEFAULT
