GE Power Management 469 Motor Management Relay 2-7
2 INSTALLATION 2.1 MECHANICAL
2
Table 2–1: 469 TERMINAL LIST
A01 RTD #1 HOT D21 ASSIGNABLE SW. 03
A02 RTD #1 COMPENSATION D22 ASSIGNABLE SW. 04
A03 RTD RETURN D23 SWITCH COMMON
A04 RTD #2 COMPENSATION D24 SWITCH +24 V DC
A05 RTD #2 HOT D25 COMPUTER RS485 +
A06 RTD #3 HOT D26 COMPUTER RS485 –
A07 RTD #3 COMPENSATION D27 COMPUTER RS485 COMMON
A08 RTD RETURN E01 R1 TRIP NC
A09 RTD #4 COMPENSATION E02 R1 TRIP NO
A10 RTD #4 HOT E03 R2 AUXILIARY COMMON
A11 RTD #5 HOT E04 R3 AUXILIARY NC
A12 RTD #5 COMPENSATION E05 R3 AUXILIARY NO
A13 RTD RETURN E06 R4 ALARM COMMON
A14 RTD #6 COMPENSATION E07 R5 BLOCK START NC
A15 RTD #6 HOT E08 R5 BLOCK START NO
A16 ANALOG OUT COMMON – E09 R6 SERVICE COMMON
A17 ANALOG OUT 1 + E10 not used
A18 ANALOG OUT 2 + E11 COIL SUPERVISION +
A19 ANALOG OUT 3 + E12 469 DRAWOUT INDICATOR
A20 ANALOG OUT 4 + F01 R1 TRIP COMMON
A21 ANALOG SHIELD F02 R2 AUXILIARY NO
A22 ANALOG INPUT 24 V DC POWER SUPPLY + F03 R2 AUXILIARY NC
A23 ANALOG INPUT 1 + F04 R3 AUXILIARY COMMON
A24 ANALOG INPUT 2 + F05 R4 ALARM NO
A25 ANALOG INPUT 3 + F06 R4 ALARM NC
A26 ANALOG INPUT 4 + F07 R5 BLOCK START COMMON
A27 ANALOG INPUT COMMON – F08 R6 SERVICE NO
B01 RTD SHIELD F09 R6 SERVICE NC
B02 AUXILIARY RS485 + F10 not used
B03 AUXILIARY RS485 – F11 COIL SUPERVISION –
B04 AUXILIARY RS485 COMMON F12 469 DRAWOUT INDICATOR
C01 ACCESS + G01 PHASE VT NEUTRAL
C02 ACCESS – G02 PHASE A VT
•
C03 469 UNDER TEST + G03 DIFFERENTIAL A CT
•
C04 469 UNDER TEST – G04 DIFFERENTIAL B CT
•
D01 RTD #7 HOT G05 DIFFERENTIAL C CT
•
D02 RTD #7 COMPENSATION G06 PHASE A CT
•
D03 RTD RETURN G07 PHASE B CT
•
D04 RTD #8 COMPENSATION G08 PHASE C CT
•
D05 RTD #8 HOT G09 1A/5A GROUND CT
•
D06 RTD #9 HOT G10 50:0.025 GROUND CT
•
D07 RTD #9 COMPENSATION G11 FILTER GROUND
D08 RTD RETURN G12 SAFETY GROUND
D09 RTD #10 COMPENSATION H01 PHASE B VT
•
D10 RTD #10 HOT H02 PHASE C VT
•
D11 RTD #11 HOT H03 DIFFERENTIAL A CT
D12 RTD #11 COMPENSATION H04 DIFFERENTIAL B CT
D13 RTD RETURN H05 DIFFERENTIAL C CT
D14 RTD #12 COMPENSATION H06 PHASE A CT
D15 RTD #12 HOT H07 PHASE B CT
D16 STARTER STATUS H08 PHASE C CT
D17 EMERGENCY RESTART H09 1A/5A GROUND CT
D18 REMOTE RESET H10 50:0.025 GROUND CT
D19 ASSIGNABLE SW. 01 H11 CONTROL POWER –
D20 ASSIGNABLE SW. 02 H12 CONTROL POWER +

GE 469 Specifications

General

Model	GE 469
Category	Relays
Frequency	50/60 Hz
Protection Functions	Overcurrent
Communication Protocols	Modbus, DNP3, IEC 61850
Display	LCD
Mounting	Panel
