APPENDIX A A.1 COMMISSIONING
A
Table A–11: SETPOINTS PAGE 11 – MONITORING
DESCRIPTION DEFAULT USER VALUE DESCRIPTION DEFAULT USER VALUE
TRIP COUNTER kvar DEMAND
Trip Counter Alarm Off kvar Demand Period 15 min.
Assign Alarm Relays Alarm kvar Demand Alarm Off
Trip Counter Alarm 25 Trips Assign Alarm Relays Alarm
Alarm Events Off kvar Demand Unit 100 kvar
STARTER FAILURE kvar Demand Alarm Events Off
Starter Failure Alarm Off kVA DEMAND
Starter Type Breaker kVA Demand Period 15 min.
Assign Alarm Relays Alarm kVA Demand Alarm Off
Starter Failure Delay 100 ms Assign Alarm Relays Alarm
Supervision Of Trip Coil Disabled kVA Demand Unit 100 kVA
Alarm Events Off kVA Demand Alarm Events Off
CURRENT DEMAND PULSE OUTPUT
Current Demand Period 15 min. Pos. kWh Pulse Output Relay Off
Current Demand Alarm Off Pos. kWh Pulse Output Interval 1 kWh
Assign Alarm Relays Alarm Pos. kvarh Pulse Out. Relay Off
Current Demand Limit 100 A Pos. kvarh Pulse Out. Interval 1 kvarh
Alarm Events Off Neg. kvarh Pulse Out. Relay Off
kW DEMAND Neg. kvarh Pulse Out. Interval 1 kvarh
kW Demand Period 15 min. Running Time Pulse Relay Off
kW Demand Alarm Off Running Time Pulse Interval 0 s
Assign Alarm Relays Alarm
kW Demand Limit 100 kW
Alarm Events Off
