GE 469

GE Power Management 469 Motor Management Relay A-13
APPENDIX A A.1 COMMISSIONING
A
Table A–13: SETPOINTS PAGE 14 – TWO-SPEED MOTOR
DESCRIPTION DEFAULT USER VALUE DESCRIPTION DEFAULT USER VALUE
SPEED 2 O/L SETUP SPEED 2 UNDERCURRENT
Speed2 Standard Curve No. 4 Block Speed2 U/C From Start 0 s
Speed2 Trip @ 1.01 x FLA 17414.5 s Speed2 U/C Alarm Off
Speed2 Trip @ 1.05 x FLA 3414.9 s Speed2 U/C Alarm Pickup 0.70 x FLA
Speed2 Trip @ 1.10 x FLA 1666.7 s Speed2 U/C Alarm Delay 1 s
Speed2 Trip @ 1.20 x FLA 795.4 s Speed2 U/C Alarm Events Off
Speed2 Trip @ 1.30 x FLA 507.2 s Speed2 U/C Trip Off
Speed2 Trip @ 1.40 x FLA 364.6 s Speed2 U/C Trip Pickup 0.70 x FLA
Speed2 Trip @ 1.50 x FLA 280.0 s Speed2 U/C Trip Delay 1 s
Speed2 Trip @ 1.75 x FLA 169.7 s
SPEED 2 ACCEL.
Speed2 Trip @ 2.00 x FLA 116.6 s Sp. 2 Accel. Timer From Start 10.0 s
Speed2 Trip @ 2.25 x FLA 86.1 s Accel. Timer From Sp. 1-2 10.0 s
Speed2 Trip @ 2.50 x FLA 66.6 s Speed Sw. Trip Sp. 2 Delay 5.0 s
Speed2 Trip @ 2.75 x FLA 53.3 s Speed2 Rated Speed 3600 RPM
Speed2 Trip @ 3.00 x FLA 43.7 s
Speed2 Trip @ 3.25 x FLA 36.6 s
Speed2 Trip @ 3.50 x FLA 31.1 s
Speed2 Trip @ 3.75 x FLA 26.8 s
Speed2 Trip @ 4.00 x FLA 23.2 s
Speed2 Trip @ 4.25 x FLA 20.5 s
Speed2 Trip @ 4.50 x FLA 18.2 s
Speed2 Trip @ 4.75 x FLA 16.2 s
Speed2 Trip @ 5.00 x FLA 14.6 s
Speed2 Trip @ 5.50 x FLA 12.0 s
Speed2 Trip @ 6.00 x FLA 10.0 s
Speed2 Trip @ 6.50 x FLA 8.5 s
Speed2 Trip @ 7.00 x FLA 7.3 s
Speed2 Trip @ 10.00 x FLA
5.6 s
Speed2 Trip @ 15.00 x FLA 5.6 s
Speed2 Trip @ 20.00 x FLA 5.6 s
Speed2 Min. Line Voltage 80%
Speed2 Istall @ Min. Vline 4.80 x FLA
Speed2 Safe Stall @ Min. Vline 20.0 s
Speed2 Acl. ISect @ Min. Vline 3.80 x FLA
Speed2 Istall @ 100% Vline 6.00 x FLA
Sp.2 Safe Stall @ 100% Vline 10.0 s
Sp.2 Acl. ISect @ 100% Vline 5.00 x FLA
