4-30 469 Motor Management Relay GE Power Management
4.6 S5 THERMAL MODEL 4 SETPOINT PROGRAMMING
4
TIME TO TRIP AT
4.50 x FLA: 18.2 s
Range: 0.5 to 99999.9 s; Step 1
Cannot be altered if Standard Curve Style is selected.
TIME TO TRIP AT
4.75 x FLA: 16.2 s
Range: 0.5 to 99999.9 s; Step 1
Cannot be altered if Standard Curve Style is selected.
TIME TO TRIP AT
5.00 x FLA: 14.6 s
Range: 0.5 to 99999.9 s; Step 1
Cannot be altered if Standard Curve Style is selected.
TIME TO TRIP AT
5.50 x FLA: 12.0 s
Range: 0.5 to 99999.9 s; Step 1
Cannot be altered if Standard Curve Style is selected.
TIME TO TRIP AT
6.00 x FLA: 10.0 s
Range: 0.5 to 99999.9 s; Step 1
Cannot be altered if Standard Curve Style is selected.
TIME TO TRIP AT
6.50 x FLA: 8.5 s
Range: 0.5 to 99999.9 s; Step 1
Cannot be altered if Standard Curve Style is selected.
TIME TO TRIP AT
7.00 x FLA: 7.3 s
Range: 0.5 to 99999.9 s; Step 1
Cannot be altered if Standard Curve Style is selected.
TIME TO TRIP AT
7.50 x FLA: 6.3 s
Range: 0.5 to 99999.9 s; Step 1
Cannot be altered if Standard Curve Style is selected.
TIME TO TRIP AT
8.00 x FLA: 5.6 s
Range: 0.5 to 99999.9 s; Step 1
Cannot be altered if Standard Curve Style is selected.
TIME TO TRIP AT
10.0 x FLA: 5.6 s
Range: 0.5 to 99999.9 s; Step 1
Cannot be altered if Standard Curve Style is selected.
TIME TO TRIP AT
15.0 x FLA: 5.6 s
Range: 0.5 to 99999.9 s; Step 1
Cannot be altered if Standard Curve Style is selected.
TIME TO TRIP AT
20.0 x FLA: 5.6 s
Range: 0.5 to 99999.9 s; Step 1
Cannot be altered if Standard Curve Style is selected.
MINIMUM ALLOWABLE
LINE VOLTAGE: 80%
Range: 70 to 95%; Step 1
Message seen only if Standard Curve Style is selected.
STALL CURRENT @ MIN
Vline: 4.80 x FLA
Range: 2.00 to 15.00 x FLA; Step 0.01
Message seen only if Standard Curve Style is selected.
SAFE STALL TIME @
MIN Vline: 20.0 s
Range: 0.5 to 999.9 s; Step: 0.1 s
Message seen only if Standard Curve Style is selected.
ACCEL. INTERSECT @
MIN Vline: 3.80 x FLA
Range: 2.00 to Istall @ min. Vline; Step: 0.01
Message seen only if Standard Curve Style is selected.
STALL CURRENT @ 100%
Vline: 6.00 x FLA
Range: 2.00 to 15.00 x FLA; Step: 0.01
Message seen only if Standard Curve Style is selected.
SAFE STALL TIME @
100% Vline: 10.0 s
Range: 0.5 to 999.9 s; Step: 0.1
Message seen only if Standard Curve Style is selected.
ACCEL. INTERSECT @
100% Vline: 5.00 x FLA
Range: 2.00 to Istall @ min. Vline; Step: 0.01
Message seen only if Standard Curve Style is selected.
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
MESSAGE
ESCAPE
