Up to five (5) message screens can be programmed under the message scratchpad area.
These messages may be notes that pertain to the installation or the motor or any other
information deemed pertinent by the user. In addition, these messages may be selected
for scanning during default message display. This might be useful for reminding operators
to perform certain tasks. The messages may be entered from the communications ports or
through the keypad. The following procedure demonstrates the use of the message
scratchpad:
1. Select the user message to be changed.
2. Press the decimal [.] key to enter text mode. An underline cursor will appear
under the first character.
3. Use the VA L U E keys to display the desired character. A space is selected like a
character.
4. Press the decimal [.] key to advance to the next character. To skip over a char-
acter press the decimal key. If an incorrect character is accidentally stored,
press the decimal key enough times to scroll the cursor around to the character.
5. When the desired message is displayed press ENTER to store or ESCAPE to quit.
The message is now permanently stored. Press ESCAPE to cancel the altered
message.
5.2.7 Clear Data
PATH: SETTINGS Z S1 469 SETUP ZV CLEAR DATA
These commands may be used to clear various historical data.
• CLEAR LAST TRIP DATA: Clears the last trip data.
• RESET MWh and Mvarh METERS: Resets the MWh and Mvarh metering to zero.
• CLEAR PEAK DEMAND DATA: Clears the peak demand values.
• CLEAR RTD MAXIMUMS: All maximum RTD temperature measurements are stored
and updated each time a new maximum temperature is established. This command
clears the maximum values.
 CLEAR
DATA [Z]
CLEAR LAST TRIP
DATA: No
Range: No, Yes
MESSAGE
RESET MWh and
Mvarh
Range: No, Yes
MESSAGE
CLEAR PEAK DEMAND
DATA: No
Range: No, Yes
MESSAGE
CLEAR RTD
MAXIMUMS: No
Range: No, Yes
MESSAGE
CLEAR ANALOG I/P
MIN/MAX: No
Range: No, Yes
MESSAGE
CLEAR TRIP
COUNTERS: No
Range: No, Yes
MESSAGE
PRESET DIGITAL
COUNTER: No
Range: No, Yes
MESSAGE
CLEAR EVENT
RECORDER: No
Range: No, Yes
