CHAPTER 2: INTRODUCTION
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 2–5
2.1.3 Order Codes
2.1.4 Example Order Codes
1. The 469-P1-LO-A20-E code specifies a 469 Motor Management Relay with 1 A CT
inputs, 25 to 60 V DC or 20 to 48 V AC control voltage, 4 to 20 mA analog outputs, and
enhanced display option with larger LCD.
2. The 469-P5-HI-A1-T-H code specifies a 469 Motor Management Relay with 5 A CT
inputs, 90 to 300 V DC or 70 to 265 V AC control voltage, 0 to 1 mA analog outputs,
enhanced display with Ethernet (10Base-T) communications, and a harsh
environment conformal coating.
2.1.5 Accessories
The following accessories are available for the 469 Motor Management Relay:
• EnerVista 469 Setup software: No-charge software provided with each relay
• Demo: Metal Carry Case in which 469 unit may be mounted
• SR 19-1 Panel: Single cutout 19-inch panel
• SR 19-2 Panel: Dual cutout 19-inch panel
• SCI Module: RS232-to-RS485 converter box designed for harsh industrial
environments
• Phase CT: 50, 75, 100, 150, 200, 250, 300, 350, 400, 500, 600, 750, 1000
• HGF3, HGF5, HGF8: For sensitive ground detection on high resistance grounded
systems.
• 469 1-inch Collar: For shallow switchgear, reduces the depth of the relay by 1 3/8
inches
• 469 3-inch Collar: For shallow switchgear, reduces the depth of the relay by 3
inches
• Optional Mounting Kit: Additional mounting support 1819-0030
Table 2–1: 469 Order Codes
469 – * – * – * – * – *
Base Unit
469 |||||
469 Motor Management Relay
Phase Current Inputs
P1 | | | |
1 A phase CT secondaries
P5 | | | |
5 A phase CT secondaries
Control Power
LO
|
|
|
|
|
|
20 to 60 V DC;
20 to 48 V AC at 48 to 62 Hz
HI
|
|
|
|
|
|
90 to 300 V DC;
70 to 265 V AC at 48 to 62 Hz
Analog Outputs
A1 | |
Four (4) 0 to 1 mA analog outputs
A20 | |
Four (4) 4 to 20 mA analog outputs
Display
||
Basic display
E |
Enhanced display, larger LCD
T |
Enhanced with Ethernet (10Base-T)
D |
Enhanced display with DeviceNet
Harsh Environment
H
Harsh (chemical) environment conformal
coating
