CHAPTER 6: ACTUAL VALUES
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 6–31
A breakdown of number of trips by type is displayed here. When the total exceeds 50000,
all counters reset to 0. This information can be cleared using the
S1 469 SETUP ZV CLEAR
DATA ZV CLEAR TRIP COUNTERS settings. Messages relating to analog inputs reflect the
programmed analog input name.
6.5.2 General Counters
PATH: ACTUAL VALUES ZV A4 MAINTENANCE ZV GENERAL COUNTERS
MESSAGE
OVERVOLTAGE
TRIPS: 0
Range: 0 to 50000
MESSAGE
PHASE REVERSAL
TRIPS: 0
Range: 0 to 50000
MESSAGE
VOLTAGE FREQUENCY
TRIPS: 0
Range: 0 to 50000
MESSAGE
POWER FACTOR
TRIPS: 0
Range: 0 to 50000
MESSAGE
REACTIVE POWER
TRIPS: 0
Range: 0 to 50000
MESSAGE
REVERSE POWER
TRIPS: 0
Range: 0 to 50000
MESSAGE
UNDERPOWER
TRIPS: 0
Range: 0 to 50000
MESSAGE
ANALOG I/P 1
TRIPS: 0
Range: 0 to 50000
MESSAGE
ANALOG I/P 2
TRIPS: 0
Range: 0 to 50000
MESSAGE
ANALOG I/P 3
TRIPS: 0
Range: 0 to 50000
MESSAGE
ANALOG I/P 4
TRIPS: 0
Range: 0 to 50000
MESSAGE
ANALOG 1-2
TRIPS: 0
Range: 0 to 50000
MESSAGE
ANALOG 3-4
TRIPS: 0
Range: 0 to 50000

GENERAL [
Z]
COUNTERS
NUMBER OF MOTOR
STARTS: 0
Range: 0 to 50000
MESSAGE
NUMBER OF EMER-
GENCY
Range: 0 to 50000
MESSAGE
NUMBER OF STARTER
OPERATIONS: 0
Range: 0 to 50000
