CHAPTER 6: ACTUAL VALUES
469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL 6–13
6.3.3 Voltage Metering
PATH: ACTUAL VALUES ZV A2 METERING DATA ZV VOLTAGE METERING
Measured voltage parameters will be displayed here.
If no VT connection type is programmed for the
S2 SYSTEM SETUP ZV VOLTAGE SENSING
ZV VT CONNECTION TYPE settings, the THIS FEATURE NOT PROGRAMMED flash
message will appear when an attempt is made to enter this group of messages.
6.3.4 Speed
PATH: ACTUAL VALUES ZV A2 METERING DATA ZV SPEED
If the Tachometer function is assigned to one of the digital inputs, the tachometer readout
may be viewed here.
If no digital input is configured as tachometer in
S3 DIGITAL INPUTS ZV ASSIGNABLE
INPUT1(4)
, the THIS FEATURE NOT PROGRAMMED flash message will appear when an
attempt is made to enter this group of messages.

VOLTAGE [
Z]
METERING
Vab: 0 Vbc:
0
Vca: 0 Volts
Range: 0 to 20000 V. Not seen if VT
Connection is set as None
MESSAGE
AVERAGE LINE
VOLTAGE: 0 Volts
Range: 0 to 20000 V. Not seen if VT
Connection is set as None
MESSAGE
Van: 0 Vbn:
0
Range: 0 to 20000 V. Seen only if VT
Connection is set as Wye
MESSAGE
AVERAGE PHASE
VOLTAGE: 0 Volts
Range: 0 to 20000 V. Seen only if VT
Connection is set as Wye
MESSAGE
SYSTEM FREQUENCY:
0.00 Hz
Range: 0.00, 20.00 to 120.00 Hz

SPEED [
Z]
TACHOMETER: 0 RPM
Range: 0 to 7200 RPM
