5–92 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 5: SETTINGS
Table 5–3: Analog Output Parameter Selection Table
PARAMETER NAME RANGE / UNITS STEP DEFAULT
MIN. MAX
Phase A Current 0 to 100000 A 1 0 100
Phase B Current 0 to 100000 A 1 0 100
Phase C Current 0 to 100000 A 1 0 100
Avg. Phase Current 0 to 100000 A 1 0 100
AB Line Voltage 50 to 20000 V 1 3200 4500
BC Line Voltage 50 to 20000 V 1 3200 4500
CA Line Voltage 50 to 20000 V 1 3200 4500
Avg. Line Voltage 50 to 20000 V 1 3200 4500
Phase AN Voltage 50 to 20000 V 1 1900 2500
Phase BN Voltage 50 to 20000 V 1 1900 2500
Phase CN Voltage 50 to 20000 V 1 1900 2500
Avg. Phase Voltage 50 to 20000 V 1 1900 2500
Hottest Stator RTD –50 to +250°C or –58 to +482°F 1 0 200
Hottest Bearing RTD –50 to +250°C or –58 to +482°F 1 0 200
Ambient RTD –50 to +250°C or –58 to +482°F1 -50 60
RTD #1 to 12 –50 to +250°C or –58 to +482°F 1 -50 250
Power Factor 0.01 to 1.00 lead/lag 0.01 0.8 lag 0.8 lead
Reactive Power -50000 to 50000 kvar 1 0 750
Real Power -50000 to 50000 kW 1 0 1000
Apparent Power 0 to 50000 kVA 1 0 1250
Thermal Capacity Used 0 to 100% 1 0 100
Relay Lockout Time 0 to 500 min. 1 0 150
Current Demand 0 to 100000 A 1 0 700
kvar Demand 0 to 50000 kvar 1 0 1000
kW Demand 0 to 50000 kW 1 0 1250
kVA Demand 0 to 50000 kVA 1 0 1500
Motor Load 0.00 to 20.00 x FLA 0.01 0.00 1.25
Analog Inputs 1-4 –50000 to +50000 1 0 +50000
Tachometer 100 to 7200 RPM 1 3500 3700
