CHAPTER 1: GETTING STARTED
Z Press the decimal [.] key to enter the text editing mode.
The first character will appear underlined as follows:.
Z Press the
VA L U E keys until the character “S” is displayed in the first
position.
Z Press the decimal [.] key to store the character and advance the cursor to
the next position.
Z Change the second character to a “t” in the same manner.
Z Continue entering characters in this way until all characters of the text
“Stn. Monitor” are entered.
Note that a space is selected like a character. If a character is entered
incorrectly, press the decimal [.] key repeatedly until the cursor returns
to the position of the error. Re-enter the character as required.
Z Once complete, press the
ENTER key to remove the solid cursor and
view the result. Once a character is entered, by pressing the
ENTER key,
it is automatically saved in flash memory, as a new settings.
SWITCH NAME:
G
eneral Sw. A
SWITCH NAME:
Stn. Monitor
