GE 469

6–8 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 6: ACTUAL VALUES
Any active alarms may be viewed here.
The various alarm and alarm status actual values reflect the Alarm Name as programmed
in the first line of the message. The status is “Active” if the condition that caused the alarm
is still present.
If the 469 chassis is only partially engaged with the case, the
ALARM, 469 NOT INSERTED
PROPERLY
service alarm appears after 1 second. Secure the chassis handle to ensure that
all contacts mate properly.
MESSAGE
REACTIVE POWER
ALARM: +2000 kvar
Range: –50000 to +50000 kvar
MESSAGE
UNDERPOWER
ALARM: 200 kW
Range: –50000 to +50000 kW
MESSAGE
TRIP COUNTER
ALARM: 25 Trips
Range: 1 to 10000 Trips
MESSAGE
STARTER FAILURE:
Trip Coil Super
Range: Trip Coil Super, Welded
Contactor, Breaker Failure
MESSAGE
CURRENT DEMAND
ALARM: 1053 A
Range: 1 to 10000 A
MESSAGE
kW DEMAND
ALARM: 505 kW
Range: –50000 to +50000 kW
MESSAGE
kvar DEMAND
ALARM: –2000 kvar
Range: –50000 to +50000 kvar
MESSAGE
kVA DEMAND
ALARM: 2062 kVA
Range: 0 to 50000 kVA
MESSAGE
ANALOG I/P 1
ALARM: 201 Units
Range: –50000 to +50000
MESSAGE
EMERGENCY
RESTART:
Range: Trip Still Present, Block Still
Present, No Trips & No Blocks
MESSAGE
ALARM, 469 NOT
INSERTED PROPERLY
Range: N/A
MESSAGE
469 NOT IN SER-
VICE
Range: Not Programmed, Output
Relays Forced, Analog Output
Forced, Test Switch Shorted
MESSAGE
RTD #1
HI
Range: 1 to 250°C
MESSAGE
ANALOG 1-2
ALARM: 50%
Range: 0 to 999 (% Diff) or 0 to 99999
(Abs Diff)
MESSAGE
ANALOG 3-4
ALARM: 50%
Range: 0 to 999 (% Diff) or 0 to 99999
(Abs Diff)
MESSAGE
OVERTORQUE
ALARM:
Range: 0.00 to 999999.9 Nm
