3–10 469 MOTOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER 3: INSTALLATION
A08 RTD Return E01 1 Trip NC
A09 RTD #4 Compensation E02 1 Trip NO
A10 RTD #4 Hot E03 2 Auxiliary Common
A11 RTD #5 Hot E04 3 Auxiliary NC
A12 RTD #5 Compensation E05 3 Auxiliary NO
A13 RTD Return E06 4 Alarm COMMON
A14 RTD #6 Compensation E07 5 Block Start NC
A15 RTD #6 Hot E08 5 Block Start NO
A16 Analog Output Common – E09 6 Service Common
A17 Analog Output 1 + E10 not used
A18 Analog Output 2 + E11 Coil Supervision +
A19 Analog Output 3 + E12 469 Drawout Indicator
A20 Analog Output 4 + F01 1 Trip Common
A21 Analog Shield F02 2 Auxiliary NO
A22 Analog In 24 V DC Power Supply + F03 2 Auxiliary NC
A23 Analog Input 1 + F04 3 Auxiliary COMMON
A24 Analog Input 2 + F05 4 Alarm NO
A25 Analog Input 3 + F06 4 Alarm NC
A26 Analog Input 4 + F07 5 Block Start Common
A27 Analog Input Common – F08 6 Service NO
B01 RTD Shield F09 6 Service NC
B02 Auxiliary RS485 + F10 not used
B03 Auxiliary RS485 – F11 Coil Supervision –
B04 Auxiliary RS485 Common F12 469 Drawout Indicator
C01 Access + G01 Phase VT Neutral
C02 Access – G02 Phase A VT
C03 469 Under Test + G03 Differential A CT
C04 469 Under Test – G04 Differential B CT
D01 RTD #7 Hot G05 Differential C CT
D02 RTD #7 Compensation G06 Phase A CT
D03 RTD Return G07 Phase B CT
D04 RTD #8 Compensation G08 Phase C CT
D05 RTD #8 Hot G09 1A/5A Ground CT
D06 RTD #9 Hot G10 50:0.025 Ground CT
D07 RTD #9 Compensation G11 Filter Ground
D08 RTD Return G12 Safety Ground
D09 RTD #10 Compensation H01 Phase B VT
D10 RTD #10 Hot H02 Phase C VT
D11 RTD #11 Hot H03 Differential A CT
D12 RTD #11 Compensation H04 Differential B CT
D13 RTD Return H05 Differential C CT
D14 RTD #12 Compensation H06 Phase A CT
D15 RTD #12 Hot H07 Phase B CT
D16 Starter Status H08 Phase C CT
D17 Emergency Restart H09 1A/5A Ground CT
D18 Remote Reset H10 50:0.025 Ground CT
D19 Assignable Switch 1 H11 Control Power –
D20 Assignable Switch 2 H12 Control Power +
Table 3–1: 469 Terminal List
Terminal Description Terminal Description
