ATS Control Panel
Manager's manual
28
2. Active Zones
Use this function to list all active zones, for example, an open door.
To list all active zones
1. Access menu option 2.
What happens next depends on whether there are any active zones:
No zones active Zones are active
All Zones are Normal
Press ENTER
Active zones are listed either one at a time, or as a list of
numbers:
Active On 4, PIR IN Managers Office
NEXT or ENTER
or
Active On 1, 2, 6.
Zone No:
2. From the display you can now:
Option Action Result
Display the complete zone name
Enter the zone number and press
[ENTER]
Displays the complete zone name.
(Excludes the status All zones are normal).
Update the list Press [NEXT] Updates the list of zone status.
Exit Press [ENTER]
Exits the menu option and returns to the display
"Code:"
See also: Menu option 1, Panel status on page 27.
