No. Description Warning Alarm/Trip Alarm/Trip Lock Parameter Reference
1 10 Volts low X
2 Live zero error (X) (X) AN-01
3 No motor (X) H-80
4 Mains phase loss (X) (X) (X) SP-12
5 DC link voltage high X
6 DC link voltage low X
7 DC over voltage X X
8 DC under voltage X X
9 Inverter overloaded X X
10 Motor Electronic Thermal Overload over temperature (X) (X) F-10
11 Motor thermistor over temperature (X) (X) F-10
12 Torque limit X X
13 Over Current X X X
14 Earth fault X X X
15 Hardware mismatch X X
16 Short Circuit X X
17 Control word timeout (X) (X) O-04
22 Hoist mechanical brake X
23 Internal fans X B-2#
24 External fans X SP-53
25 Brake resistor short-circuited X
26 Brake resistor power limit (X) (X) B-13
27 Brake chopper short-circuited X X
28 Brake check (X) (X) B-15
29 Heatsink temp X X X
30 Motor phase U missing (X) (X) (X) H-78
31 Motor phase V missing (X) (X) (X) H-78
32 Motor phase W missing (X) (X) (X) H-78
33 Inrush fault X X
34 Network communication fault X X
36 Mains failure X X
37 Phase imbalance X
38 Internal fault X X
39 Heatsink sensor X X
40 Overload of Digital Output Terminal 27 (X) E-00 & E-51
41 Overload of Digital Output Terminal 29 (X) E-00 & E-52
42 Overload of Digital Output on X30/6 or Overload of Digital
Output on X30/7
(X) E-56 & E-57
45 Earth fault 2 X X X
46 Power card supply X X
47 24 V supply low X X X
48 1.8 V supply low X X
49 Speed limit X X
50 Auto Tune calibration failed X
51 Auto Tune check U
nom
and I
nom
X
52 Auto Tune low I
nom
X
53 Auto Tune motor too big X
54 Auto Tune motor too small X
55 Auto Tune parameter out of range X
56 Auto Tune interrupted by user X
57 Auto Tune timeout X
58 Auto Tune internal fault X X
59 Current limit X
60 External interlock X X
61 Tracking Error (X) (X) H-20
62 Output Frequency at Maximum Limit X
63 Mechanical brake low (X) B-20
Table 4.2: Alarm/Warning code list
