AF-7
AF-70 LP
3
10
9
3.5. MechanicalDimensions–IP66(Nema4X)EnclosedUnits
Driveunit
Size
A
B
D
E
F
G
H
I
J
Weight
mm
in
mm
in
mm
in
mm
in
mm
In
mm
in
mm
in
mm
in
mm
in
kg
lb
1
232.0
9.13
207.0
8.15
189.0
7.44
25.0
0.98
179.0
7.05
161.0
6.34
148.5
5.85
4.0
0.16
8.0
0.31
3.1
6.8
2
257.0
10.12
220.0
8.67
200.0
7.87
28.5
1.12
187.0
7.36
188.0
7.40
176.0
6.93
4.2
0.17
8.5
0.33
4.1
9.0
3
310.0
12.20
276.5
10.89
251.5
9.90
33.4
1.31
252
9.92
211.0
8.30
197.5
7.78
4.2
0.17
8.5
0.33
7.6
16.7
MountingBolts
AllUnitSizes
4xM4(#8)
TighteningTorques
AllUnitSizes
ControlTerminals
0.5Nm(4.5lb-in)
PowerTerminals
1Nm(9lb-in)
3.6. Guidelinesformounting(IP66Units)
Beforemountingthedrive,ensurethatthechosenlocationmeetstheenvironmentalconditionrequirementsforthedriveshowninsection9.1
Thedrivemustbemountedvertically,onasuitableflatsurface
Theminimummountingclearancesasshowninthetablebelowmustbeobserved
Themountingsiteandchosenmountingsshouldbesufficienttosupporttheweightofthedrives
Usingthedriveasatemplate,orthedimensionsshownabove,markthelocationsrequiredfordrilling
Suitablecableglandstomaintaintheingressprotectionofthedrivearerequired.Glandholesforpowerandmotorcablesarepre-mouldedinto
thedriveenclosure,recommendedglandsizesareshownabove.Glandholesforcontrolcablesmaybecutasrequired.
DriveunitSize
XAbove&Below
YEitherSide
mm
in
mm
in
1
200
7.87
10
0.39
2
200
7.87
10
0.39
3
200
7.87
10
0.39
Note:
Typicaldriveheatlossesareapproximately3%ofoperatingload
conditions.
Aboveareguidelinesonlyandtheoperatingambienttemperatureof
thedriveMUSTbemaintainedatalltimes.
CableGlandSizes
DriveunitSize
PowerCable
MotorCable
ControlCables
1
M20(PG13.5)
M20(PG13.5)
M20(PG13.5)
2
M25(PG21)
M25(PG21)
M20(PG13.5)
3
M25(PG21)
M25(PG21)
M20(PG13.5)
