GE CT-9800

GE MEDICAL SYSTEMS CT 9800 QUICK SYSTEM
Rev. 3 Direction 18000
8-6-2
ELECTRO - STATIC DISCHARGE
STATIC KILLS ELECTRONIC CIRCUITS!
46-194427P231 ESD Control Kit - Available thru PRO. If you don’t have one in your tool
kit, order one today
Always wear an ESD wrist strap when handling or touching electronic devices. Put the wrist strap ON
first! Take the wrist strap OFF last!
Remove electronic parts from anti-static bags ONLY
at a static safe work area (using a grounded wrist
strap & grounded mat).
********* STAY GROUNDED *********
REMEMBER!:
TO FEEL STATIC 3500 volts or more required
TO HEAR STATIC 4500 volts or more required
TO SEE STATIC SPARK 5000 volts or more required
DEVICE TYPE Range of ESD Damage
Susceptibility in Volts
VMOS (VLSI Gate Arrays) 30 - 1800
MOSFET 100 - 200
GaaFET 100 - 300
EPROM 100
JFET 140 - 7000
SAW 150 - 500
OP-AMP 190 - 2500
CMOS 250 - 3000
SCHOTTKY DIODES 300 - 2500
FILM RESISTORS 300 - 3000
BIPOLAR TRANSISTORS 380 - 7000
ECL 500 - 1500
SCR 680 - 1000
SCHOTTKY TTL 1000 - 2500
