GE CT-9800

GE MEDICAL SYSTEMS CT 9800 QUICK SYSTEM
Rev. 9 Direction 18000
4-3-26
5. Mount and load Argus Diagnostics Tape “DGC Diagnostic Tape” . If necessary, refer to DTOS Vol #1,
Part 1 for details. Place Tape Drive on-line, Low Density.
6. Load 6236 DIAG to test controller.
Reset computer and observe the following dialog and type the underlined response.
==> LOAD 6236 DIAG ’CR’
LOAD:
6236 DIAG REV.nn
HELP OR FIELD REPLACEABLE UNIT INFORMATION? (YES/NO) NO
SET SWREG AS PER 8.0, HIT CR TO CONTINUE - ’CR’
OCTAL OR HEX DISK/MEMORY DATA MODE (OCT/HEX) OCT
INTER PROCESSOR BUS IN SYSTEM? (YES/NO) NO ’CR’
DEVICE CODE (OCTAL) = 24
UNITS TO TEST OR (CR) ONLY FOR CONTROLLER ONLY - ’CR’
TESTING (Indicates Controller test in progress)
PASS 1 (Indicates all test have been executed once)
NOTE: Program will continue to run. Reset after 1 pass. Any errors will be printed to the console.
Run time for Controller only testing is 0.5 minutes.
7. Reset computer and load 6236 FUNC for diagnostics track only; run 1 complete pass.
This test should be run on both Argus Drives of a Dual Drive system.
==> LOAD 6236 FUNC ’CR’
LOAD:
6236 FUNC REV.nn
HELP ? (YES/NO) NO
SET SWREG AS PER 8.0, HIT CR TO CONTINUE - ’CR’
OCTAL OR HEX DISK/MEMORY DATA MODE (OCT/HEX) OCT
DEVICE CODE (OCTAL) = 24
UNITS TO TEST - 1 (Dual Drive Systems type 1,2)
354, 592 MBYTES (354) -
UNIT:1 - 354
UNIT:2 - 354 (Only asked for Dual Drive)
DRIVE WRITE MODE - DIAGNOSTIC TRACK ONLY, OR ALL TRACKS (DIAG, ALL)-
UNIT:1 - DIAG
UNIT:2 - DIAG (Only asked for Dual Drive)
TESTING UNITS 1 (Indicates Single Drive test in progress)
TESTING UNITS 1,2
(Indicates Dual Drive test in progress)
(Status of swreg and version status will be printed)
PASS (Indicates complete pass through the tests.)
NOTE: Program will run continue to run. Reset after 1 pass. Any errors will be printed to the
console. Run time for Diagnostics Track only testing is 6 minutes for each unit being tested.
