GE D25 User Manual

D25
User's Manual
GE Grid Solutions
168
994-0081-3.00-21 GE Information
MODIFICATION RECORD
Version Revision Date Change Description
1.00 1 Mar 12, 2003 Created
2.00 0 May 12, 2006 Merged with 994-0076, removed old information.
2.00 1 Dec 6, 2006 Corrected Wetting options for High Voltage Digital Input cards. Clarify Case # 20061020-0254
Changed part numbers 450-0116 to 450-0107 and 450-0117 to 450-0108. Clarify Case #
20061120-0372-1.
Added note for serial input resistance in Communication ports section. Clarify Case #
20061102-0363.
Added note (IRIG-B is received on CTS Port) to the IRIG-B notes in Communication ports
section. Clarify Case # 20061027-0326-2.
2.00
2
Oct. 23, 2007
Updated ordering guide power supply option (1).
2.00
3
Jun 4, 2008
Updated p. 129 per CC#20080529-0279.
3.00
0
Feb 23, 2009
Added High Current Control Card
Updated Ordering Information, Obsolete parts
Added product bulletin information
Corrected Fuse Specifications in Fuse Replacement section
3.00
1
Mar 24, 2009
Removed D25KE FACE-40 specification row (p. 144)
Added Max Ambient Temp Spec for HCKE (p. 147)
Updated Chapter 8: Troubleshooting.
2 Jul 21, 2011 Updated Technical Support contact information.
3
Feb 17, 2012
Added caution note for installing the Memory Expansion Card.
4
Jun 19, 2012
Replaced Ethernet XCOM Card section with D25 Ethernet Card 100Base section.
5
Jul 4, 2012
Added SQL and Jabber provision note to section: D25 Ethernet Card 100Base.
6
Apr 23, 2013
Added BootROM part number to the Reporting Problems section.
7 Jun 4, 2013 Replaced 580-0994: D25 10Base-T XCOM card with 504-0305LF: D25 100FX and 10/100TX
XCOM card, two multimode ST fiber optic ports and two RJ45 ports.
8
Aug 15, 2013
Updated torque values for the ground stud.
9
Oct 11, 2013
Added RoHS table.
10 Jan 22, 2014 Added information on the Color Graphic Display Panel: GDP 300
11 May 29, 2014 Added note in the AC Analog Inputs sections on configuring a D25 device with all AC inputs
configured as PT inputs.
Added Testing and Certification specifications.
12
Sep 10, 2014
Fixed product name error in RoHS section.
Fixed link in “To load a configuration file onto the CGDP from a USB flash drive” section.
Added Appendix D: Installing and Connecting DNP3 I/O Modules
13 Feb 20, 2015 Added 100Base-FX wavelength information to D25 Ethernet Card 100Base section.
14 Apr 6, 2015 Added additional information for the GDP and CGDP setup.
15
Jun 10, 2015
Compatibility content added to the D25 Ethernet Card 100Base section.
The Ethernet card 580-0993 is replaced by 504-0305LF.
The D25 Analog Interface Card 504-0009 is obsolete.
16
Jul 29, 2015
Updated Appendix A, Product Specifications > Electrical Specifications > Auxiliary Digital
Outputs.
17
Nov 5, 2015
Added EAC compliance content.
Added battery tab removal information.
Replaced Sensa Control Digital with Quasar Controls.
18 Jun 17, 2016 Rebranded for GE Grid Solutions.
Specifications reference added to Radio Keying Output and System Fail Output sections.
Removed the following products from D25KE Configuration Summary: 517-0448, 517-0450,
517-0451, 517-0453, 517-0454, and 517-0455.
Added fuse information for fuses F1 and F2 on 521-0119.
Added legacy system backplane figure.
19
June 22, 2016
Added further fuse replacement information.
Corrected part numbers for D20 KI interposing relay panels.
20 Feb 3, 2017 Removed references to ConfigPro due to discontinuance of ConfigPro.
Updated battery life for NVRAM on the 20 MB Memory Expansion board.

GE D25 Specifications

General

Brand	GE
Model	D25
Category	Controller
Language	English
