Chapter 4. Printing Data
4.3 Printing Logs
Use the LOG submenu to print logged measurement data, from a log file in the meter’s memory. The data may be
printed in either numeric or graphical format, with a user specified time increment.
IMPORTANT: Make sure that a printer has been properly set up before proceeding with this section.
To print logged measurement data, refer to Figure 15 on page 91, and complete the following steps:
1. To access the Print Menu, press the
[PRNT] key.
Note: The Print Menu is not protected by the security feature and a password is never required to access this menu.
2. Press [F2] = LOG.
3. At the Format prompt, press [F1] to print the log in numeric format or press [F2] to print the log in graphical format.
4. Use the [, [ and [F1]-[F4] keys to select a log file to print.
Note: At the NAME prompt, the option bar shows the names of all completed or active log files currently stored in
memory. If an active log is selected for printing, only the data already accumulated at the time of the print
command will be printed.
5. Enter the number of the First Page of the log to print and press
[ENT]. (This prompt does not appear if the log file is
only one page long.)
6. Enter the total number of log pages to print and press [ENT]. (This prompt does not appear if the log file is only one
page long.)
• If you chose [F1] (Numeric) at step 3, see the section below.
• If you chose [F2] (Graphic) at step 3, go to the next page.
4.3.1 Numeric Format
After the numeric format (and starting page and number of pages, if applicable) is chosen, the Model GF868 returns to
the standard data display screen and begins printing the log file. The printout continues until the entire log has been
printed or until a STOP command is issued (see the instructions for the STOP submenu). A portion of a typical printout is
shown in Figure 5.
Figure 5: A Typical Numeric Printout
Start Time
End Date
End Time
HH:MM:SS
ACF/HR
VOLUM
ACF
+TOTL
FT/S
SNDSP
Start Date
LOG MESSAGE
LOG NAME Page# 1
LOG DUMP
09 SEP 97
11:50:43 AM
09 SEP 97
11:54:45 PM
Ch1 Ch1 Ch2
To Next Page
