Chapter 4. Printing Data
64 DigitalFlow™ GF868 Programming Manual (1-Channel)
4.3.2 Graphical Format
After the graphical format (and starting page and number of pages, if applicable) is chosen, complete the following
additional steps:
7. Enter the desired maximum value for the Y (vertical) axis and press [ENT].
Note: Enter a Y AXIS MAX value that is larger than the largest logged measurement value.
8. At the Y Range prompt, press [F1] to show only the positive Y axis or press [F2] to display both the positive and
negative y axis.
The Model GF868 returns to the standard data display screen and begins printing the log file. The printout continues
until the entire log has been printed or until a STOP command is issued (see the instructions for the STOP submenu). A
portion of a typical printout is shown in Figure 6.
Figure 6: A Typical Graphical Printout
0.0
.1
.2
.3
.4
.5
.6
.7
.8
.9
1.0
0.0
.1
.2
.4
.3
.5
.7
.6
.8
.9
1.0
CHANNEL NAME
CHANNEL MESSAGE
X-AXIS 50 seconds PER-DIV
Y-AXIS MAX 500 ACF/M
START TIME
03:27:01 PM
20 OCT 97
END TIME
03:28:46 PM
20 OCT 97
