GE Multilin G30 Generator Protection System B-19
APPENDIX B B.4 MEMORY MAPPING
B
Synchrocheck Actual Values (Read Only) (4 modules)
2400 Synchrocheck 1 Delta Voltage -1000000000000 to
1000000000000
V1F060 0
2402 Synchrocheck 1 Delta Frequency 0 to 655.35 Hz 0.01 F001 0
2403 Synchrocheck 1 Delta Phase 0 to 180 (not 0 to 359.9) degrees 0.1 F001 0
2404 ...Repeated for Synchrocheck 2
2408 ...Repeated for Synchrocheck 3
240C ...Repeated for Synchrocheck 4
Field Unit Raw Data Settings (Read/Write Setting)
2460 Field Raw Data Port 0 to 7 --- 1 F244 6 (H1a)
2461 Field Raw Data Freeze 0 to 1 --- 1 F102 0 (Disabled)
Remote Double-Point Status Inputs (Read/Write Setting Registers) (5 modules)
2540 Remote Double-point Status Input 1 Device 1 to 32 --- 1 F001 1
2541 Remote Double-point Status Input 1 Item 0 to 64 --- 1 F606 0 (None)
2542 Remote Double-point Status Input 1 Name 1 to 64 --- 1 F205 "RemDPS Ip 1"
2548 Remote Double-point Status Input 1 Events 0 to 1 --- 1 F102 0 (Disabled)
2549 ... Repeated for Remote Double-point Status Input 2
2552 ... Repeated for Remote Double-point Status Input 3
255B ... Repeated for Remote Double-point Status Input 4
2564 ... Repeated for Remote Double-point Status Input 5
IEC 61850 GGIO5 Configuration (Read/Write Setting Registers) (16 modules)
26D0 IEC 61850 GGIO5 uinteger Input 1 Operand --- --- --- F612 0
26D1 IEC 61850 GGIO5 uinteger Input 2 Operand --- --- --- F612 0
26D2 IEC 61850 GGIO5 uinteger Input 3 Operand --- --- --- F612 0
26D3 IEC 61850 GGIO5 uinteger Input 4 Operand --- --- --- F612 0
26D4 IEC 61850 GGIO5 uinteger Input 5 Operand --- --- --- F612 0
26D5 IEC 61850 GGIO5 uinteger Input 6 Operand --- --- --- F612 0
26D6 IEC 61850 GGIO5 uinteger Input 7 Operand --- --- --- F612 0
26D7 IEC 61850 GGIO5 uinteger Input 8 Operand --- --- --- F612 0
26D8 IEC 61850 GGIO5 uinteger Input 9 Operand --- --- --- F612 0
26D9 IEC 61850 GGIO5 uinteger Input 10 Operand --- --- --- F612 0
26DA IEC 61850 GGIO5 uinteger Input 11 Operand --- --- --- F612 0
26DB IEC 61850 GGIO5 uinteger Input 12 Operand --- --- --- F612 0
26DC IEC 61850 GGIO5 uinteger Input 13 Operand --- --- --- F612 0
26DD IEC 61850 GGIO5 uinteger Input 14 Operand --- --- --- F612 0
26DE IEC 61850 GGIO5 uinteger Input 15 Operand --- --- --- F612 0
26DF IEC 61850 GGIO5 uinteger Input 16 Operand --- --- --- F612 0
IEC 61850 Received Integers (Read Only Actual Values) (16 modules)
26F0 IEC 61850 Received uinteger 1 0 to 4294967295 --- 1 F003 0
26F2 IEC 61850 Received uinteger 2 0 to 4294967295 --- 1 F003 0
26F4 IEC 61850 Received uinteger 3 0 to 4294967295 --- 1 F003 0
26F6 IEC 61850 Received uinteger 4 0 to 4294967295 --- 1 F003 0
26F8 IEC 61850 Received uinteger 5 0 to 4294967295 --- 1 F003 0
26FA IEC 61850 Received uinteger 6 0 to 4294967295 --- 1 F003 0
26FC IEC 61850 Received uinteger 7 0 to 4294967295 --- 1 F003 0
26FE IEC 61850 Received uinteger 8 0 to 4294967295 --- 1 F003 0
2700 IEC 61850 Received uinteger 9 0 to 4294967295 --- 1 F003 0
2702 IEC 61850 Received uinteger 10 0 to 4294967295 --- 1 F003 0
2704 IEC 61850 Received uinteger 11 0 to 4294967295 --- 1 F003 0
2706 IEC 61850 Received uinteger 12 0 to 4294967295 --- 1 F003 0
2708 IEC 61850 Received uinteger 13 0 to 4294967295 --- 1 F003 0
270A IEC 61850 Received uinteger 14 0 to 4294967295 --- 1 F003 0
270C IEC 61850 Received uinteger 15 0 to 4294967295 --- 1 F003 0
270E IEC 61850 Received uinteger 16 0 to 4294967295 --- 1 F003 0
Table B–10: MODBUS MEMORY MAP (Sheet 11 of 64)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
