B-20 G30 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
Source Current THD and Harmonics (Read Only) (4 modules)
2800 Ia THD for Source 1 0 to 99.9 --- 0.1 F001 0
2801 Ia Harmonics for Source 1 - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
2821 Ib THD for Source 1 0 to 99.9 --- 0.1 F001 0
2822 Ib Harmonics for Source 1 - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
283A Reserved (8 items) 0 to 0.1 --- 0.1 F001 0
2842 Ic THD for Source 1 0 to 99.9 --- 0.1 F001 0
2843 Ic Harmonics for Source 1 - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
285B Reserved (8 items) 0 to 0.1 --- 0.1 F001 0
2863 ...Repeated for Source 2
28C6 ...Repeated for Source 3
2929 ...Repeated for Source 4
Expanded FlexStates (Read Only)
2B00 FlexStates, one per register (256 items) 0 to 1 --- 1 F108 0 (Off)
Expanded Contact Input/Output States (Read Only)
2D00 Contact Input States, one per register (96 items) 0 to 1 --- 1 F108 0 (Off)
2D80 Contact Output States, one per register (64 items) 0 to 1 --- 1 F108 0 (Off)
2E00 Virtual Output States, one per register (96 items) 0 to 1 --- 1 F108 0 (Off)
Expanded Remote Input/Output Status (Read Only)
2F00 Remote Device States, one per register (32 items) 0 to 1 --- 1 F155 0 (Offline)
2F80 Remote Input States, one per register (64 items) 0 to 1 --- 1 F108 0 (Off)
Oscillography Values (Read Only)
3000 Oscillography Number of Triggers 0 to 65535 --- 1 F001 0
3001 Oscillography Available Records 0 to 65535 --- 1 F001 0
3002 Oscillography Last Cleared Date 0 to 400000000 --- 1 F050 0
3004 Oscillography Number Of Cycles Per Record 0 to 65535 --- 1 F001 0
Oscillography Commands (Read/Write Command)
3005 Oscillography Force Trigger 0 to 1 --- 1 F126 0 (No)
3011 Oscillography Clear Data 0 to 1 --- 1 F126 0 (No)
Oscillography Analog Values (Read Only)
3012 Oscillography Number of Triggers 0 to 32767 --- 1 F001 0
User-Programmable Fault Report Commands (Read/Write Command)
3060 User Fault Report Clear 0 to 1 --- 1 F126 0 (No)
User-Programmable Fault Report Actual Values (Read Only)
3070 Newest Record Number 0 to 65535 --- 1 F001 0
3071 Cleared Date 0 to 4294967295 --- 1 F050 0
3073 Report Date (10 items) 0 to 4294967295 --- 1 F050 0
User-Programmable Fault Report (Read/Write Setting) (2 modules)
3090 Fault Report 1 Fault Trigger 0 to 4294967295 --- 1 F300 0
3092 Fault Report 1 Function 0 to 1 --- 1 F102 0 (Disabled)
3093 Fault Report 1 Prefault Trigger 0 to 4294967295 --- 1 F300 0
3095 Fault Report Analog Channel 1 (32 items) 0 to 65536 --- 1 F600 0
30B5 Fault Report 1 Reserved (5 items) --- --- --- F001 0
30BA ...Repeated for Fault Report 2
Modbus File Transfer (Read/Write)
3100 Name of file to read --- --- --- F204 (none)
Modbus File Transfer Values (Read Only)
3200 Character position of current block within file 0 to 4294967295 --- 1 F003 0
3202 Size of currently-available data block 0 to 65535 --- 1 F001 0
3203 Block of data from requested file (122 items) 0 to 65535 --- 1 F001 0
Security (Read/Write Setting)
3280 Administrator Alphanumeric Password Setting --- --- --- F202 (none)
Security (Read Only)
328A Administrator Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Table B–10: MODBUS MEMORY MAP (Sheet 12 of 64)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
