GE Multilin G30 Generator Protection System B-21
APPENDIX B B.4 MEMORY MAPPING
B
Security (Read/Write)
328B Administrator Alphanumeric Password Entry --- --- --- F202 (none)
Security (Read/Write Setting)
3295 Supervisor Alphanumeric Password Setting --- --- --- F202 (none)
Security (Read Only)
329F Supervisor Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
32A0 Supervisor Alphanumeric Password Entry --- --- --- F202 (none)
Security (Read/Write Setting)
32AA Engineer Alphanumeric Password Setting --- --- --- F202 (none)
Security (Read Only)
32B4 Engineer Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
32B5 Engineer Alphanumeric Password Entry --- --- --- F202 (none)
Security (Read/Write Setting)
32BF Operator Alphanumeric Password Setting --- --- --- F202 (none)
Security (Read Only)
32C9 Operator Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
32CA Operator Alphanumeric Password Entry --- --- --- F202 (none)
Security (Read/Write Setting)
32D4 Observer Alphanumeric Password Setting --- --- --- F202 (none)
Security (Read Only)
32DE Observer Alphanumeric Password Status 0 to 1 --- 1 F102 0 (Disabled)
Security (Read/Write)
32DF Observer Alphanumeric Password Entry --- --- 1 F202 (none)
Security (Read Only)
32E9 Reserved for password settings of future roles (63 items) 0 to 65535 --- 1 F001 0
3328 Security Status Indicator 0 to 65535 --- 1 F618 0
Security (Read/Write Setting)
3329 Session Lockout 0 to 99 --- 1 F001 3
332A Session Lockout Period 0 to 9999 min 1 F001 3
332B Load Factory Defaults 0 to 1 --- 1 F126 0 (No)
332C Syslog Server IP Address 0 to 4294967295 --- 1 F003 0
332E Syslog Server Port Number 1 to 65535 --- 1 F001 514
Security Supervisory (Read/Write Setting)
3331 Device Authentication Enable 0 to 1 --- 1 F126 1 (Yes)
3332 Supervisor Role Enable 0 to 1 --- 1 F102 0 (Disabled)
3333 Lock Relay 0 to 1 --- 1 F102 0 (Disabled)
3334 Factory Service Mode Enable 0 to 1 --- 1 F102 0 (Disabled)
3335 Failed Authentication Alarm Enable 0 to 1 --- 1 F102 1 (Enabled)
3336 Firmware Lock Alarm 0 to 1 --- 1 F102 1 (Enabled)
3337 Settings Lock Alarm 0 to 1 --- 1 F102 1 (Enabled)
3338 Bypass Access 0 to 3 --- 1 F628 0 (Disabled)
333A Serial Inactivity Timeout 1 to 9999 --- 1 F001 1
Security Command (Read/Write Command)
3350 Operator Logoff 0 to 1 --- 1 F126 0 (No)
3351 Engineer Logoff 0 to 1 --- 1 F126 0 (No)
3352 Administrator Logoff 0 to 1 --- 1 F126 0 (No)
3353 Clear Security Data 0 to 1 --- 1 F126 0 (No)
Security Reserved Modbus Registers (Read/Write)
3360 Address 0x3360 reserved for serial login (20 items) 0 to 9999 --- 1 F001 3
3374 Address 0x3374 reserved for serial logout 0 to 9999 --- 1 F001 3
Table B–10: MODBUS MEMORY MAP (Sheet 13 of 64)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
