723B Neutral Directional Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
723C Neutral Directional Overcurrent 1 Polarizing Voltage 0 to 1 --- 1 F231 0 (Calculated V0)
723D Neutral Directional Overcurrent 1 Op Current 0 to 1 --- 1 F196 0 (Calculated 3I0)
723E Neutral Directional Overcurrent 1 Offset 0 to 250 ohms 0.01 F001 0
723F Neutral Directional Overcurrent 1 Pos Seq Restraint 0 to 0.5 --- 0.001 F001 63
7240 Reserved 0 to 1 --- 1 F001 0
7241 ...Repeated for Neutral Directional Overcurrent 2
Negative-Sequence Directional Overcurrent (Read/Write Grouped Settings) (2 modules)
7260 Negative Sequence Directional Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7261 Negative Sequence Directional Overcurrent 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
7262 Negative Sequence Directional Overcurrent 1 Type 0 to 1 --- 1 F179 0 (Neg Sequence)
7263 Neg Sequence Directional Overcurrent 1 Forward ECA 0 to 90 ° Lag 1 F002 75
7264 Neg Seq Directional Overcurrent 1 Forward Limit Angle 40 to 90 degrees 1 F001 90
7265 Neg Sequence Directional Overcurrent 1 Forward Pickup 0.015 to 30 pu 0.005 F001 50
7266 Neg Seq Directional Overcurrent 1 Reverse Limit Angle 40 to 90 degrees 1 F001 90
7267 Neg Sequence Directional Overcurrent 1 Reverse Pickup 0.015 to 30 pu 0.005 F001 50
7268 Negative Sequence Directional Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7269 Negative Sequence Directional Overcurrent 1 Block 0 to 4294967295 --- 1 F300 0
726B Negative Sequence Directional Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
726C Negative Sequence Directional Overcurrent 1 Offset 0 to 250 ohms 0.01 F001 0
726D Negative Sequence Directional Overcurrent 1 Pos Seq
Restraint
0 to 0.5 --- 0.001 F001 63
726E Reserved (3 items) 0 to 1 --- 1 F001 0
7271 ...Repeated for Neg Seq Directional Overcurrent 2
Disconnect (Breaker) Switch (Read/Write Setting) (16 modules)
74A0 Disconnect Switch 1 Function 0 to 1 --- 1 F102 0 (Disabled)
74A1 Disconnect Switch 1 Name --- --- --- F206 “SW 1"
74A4 Disconnect Switch 1 Mode 0 to 1 --- 1 F157 0 (3-Pole)
74A5 Disconnect Switch 1 Open 0 to 4294967295 --- 1 F300 0
74A7 Disconnect Switch 1 Block Open 0 to 4294967295 --- 1 F300 0
74A9 Disconnect Switch 1 Close 0 to 4294967295 --- 1 F300 0
74AB Disconnect Switch 1 Block Close 0 to 4294967295 --- 1 F300 0
74AD Disconnect Switch 1 Phase A / Three-pole Closed 0 to 4294967295 --- 1 F300 0
74AF Disconnect Switch 1 Phase A / Three-pole Opened 0 to 4294967295 --- 1 F300 0
74B1 Disconnect Switch 1 Phase B Closed 0 to 4294967295 --- 1 F300 0
74B3 Disconnect Switch 1 Phase B Opened 0 to 4294967295 --- 1 F300 0
74B5 Disconnect Switch 1 Phase C Closed 0 to 4294967295 --- 1 F300 0
74B7 Disconnect Switch 1 Phase C Opened 0 to 4294967295 --- 1 F300 0
74B9 Disconnect Switch 1 Operate Time 0 to 65.535 s 0.001 F001 70
74BA Disconnect Switch 1 Alarm Delay 0 to 65.535 s 0.001 F003 0
74BC Disconnect Switch 1 Events 0 to 1 --- 1 F102 0 (Disabled)
74BD Reserved (2 items) --- --- --- F001 0
74BF ...Repeated for Disconnect Switch 2
74DE ...Repeated for Disconnect Switch 3
74FD ...Repeated for Disconnect Switch 4
751C ...Repeated for Disconnect Switch 5
753B ...Repeated for Disconnect Switch 6
755A ...Repeated for Disconnect Switch 7
7579 ...Repeated for Disconnect Switch 8
7598 ...Repeated for Disconnect Switch 9
75B7 ...Repeated for Disconnect Switch 10
75D6 ...Repeated for Disconnect Switch 11
75F5 ...Repeated for Disconnect Switch 12
7614 ...Repeated for Disconnect Switch 13
Table B–10: MODBUS MEMORY MAP (Sheet 35 of 64)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
