7633 ...Repeated for Disconnect Switch 14
7652 ...Repeated for Disconnect Switch 15
Thermal Overload Protection (Read/Write Settings) (2 modules)
7788 Thermal Protection 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7789 Thermal Protection 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
778A Thermal Protection 1 Base Current 0.2 to 3 pu 0.01 F001 80
778B Thermal Protection 1 K Factor 1 to 1.2 --- 0.05 F001 110
778C Thermal Protection 1 Trip Time Constant 0 to 1000 min. 1 F001 45
778D Thermal Protection 1 Reset Time Constant 0 to 1000 min. 1 F001 45
778E Thermal Protection 1 Minimum Reset Time 0 to 1000 min. 1 F001 20
778F Thermal Protection 1 Reset 0 to 4294967295 --- 1 F300 0
7791 Thermal Protection 1 Block 0 to 4294967295 --- 1 F300 0
7793 Thermal Protection 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7794 Thermal Protection 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7795 Reserved (2 items) --- --- --- F001 0
7797 Repeated for Thermal Protection 2
Ohm Inputs (Read/Write Setting) (2 modules)
77F8 Ohm Inputs 1 Function 0 to 1 --- 1 F102 0 (Disabled)
77F9 Ohm Inputs 1 ID --- --- --- F205 "Ohm Ip 1 "
77FF Ohm Inputs 1 Reserved (9 items) 0 to 65535 --- 1 F001 0
7808 ...Repeated for Ohm Inputs 2
Underfrequency (Read/Write Setting) (6 modules)
7A80 Underfrequency 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7A81 Underfrequency 1 Block 0 to 4294967295 --- 1 F300 0
7A83 Underfrequency 1 Min Current 0.1 to 1.25 pu 0.01 F001 10
7A84 Underfrequency 1 Pickup 20 to 65 Hz 0.01 F001 5950
7A85 Underfrequency 1 Pickup Delay 0 to 65.535 s 0.001 F001 2000
7A86 Underfrequency 1 Reset Delay 0 to 65.535 s 0.001 F001 2000
7A87 Underfrequency 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
7A88 Underfrequency 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7A89 Underfrequency 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7A8A Underfrequency 1 Reserved (5 items) 0 to 1 --- 1 F001 0
7A8F ...Repeated for Underfrequency 2
7A9E ...Repeated for Underfrequency 3
7AAD ...Repeated for Underfrequency 4
7ABC ...Repeated for Underfrequency 5
7ACB ...Repeated for Underfrequency 6
User Programmable Pushbuttons (Read/Write Setting) (16 modules)
7B60 User Programmable Pushbutton 1 Function 0 to 2 --- 1 F137 0 (Disabled)
7B61 User Programmable Pushbutton 1 Top Line --- --- --- F202 (none)
7B6B User Programmable Pushbutton 1 On Text --- --- --- F202 (none)
7B75 User Programmable Pushbutton 1 Off Text --- --- --- F202 (none)
7B7F User Programmable Pushbutton 1 Drop-Out Time 0 to 60 s 0.05 F001 0
7B80 User Programmable Pushbutton 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7B81 User Programmable Pushbutton 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7B82 User Programmable Pushbutton 1 LED Operand 0 to 4294967295 --- 1 F300 0
7B84 User Programmable Pushbutton 1 Autoreset Delay 0.2 to 600 s 0.1 F001 10
7B85 User Programmable Pushbutton 1 Autoreset Function 0 to 1 --- 1 F102 0 (Disabled)
7B86 User Programmable Pushbutton 1 Local Lock Operand 0 to 4294967295 --- 1 F300 0
7B88 User Programmable Pushbutton 1 Message Priority 0 to 2 --- 1 F220 0 (Disabled)
7B89 User Programmable Pushbutton 1 Remote Lock Operand 0 to 4294967295 --- 1 F300 0
7B8B User Programmable Pushbutton 1 Reset Operand 0 to 4294967295 --- 1 F300 0
7B8D User Programmable Pushbutton 1 Set Operand 0 to 4294967295 --- 1 F300 0
7B8F User Programmable Pushbutton 1 Hold 0 to 10 s 0.1 F001 1
Table B–10: MODBUS MEMORY MAP (Sheet 36 of 64)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
